Our range is now getting even stronger. From now on, we also stock Hydro-Mec worm gears in size 85, a powerful solution that can handle torques up to 347 Nm. With the new size in place, we now cover the entire range from size 30 up to 85 – always with fast delivery and high quality.

Standard version

Single output shaft

Double output shaft

Proven standard with new possibilities

Our standard worm gearboxes from Hydro-Mec have long been one of our most appreciated product ranges. They are simple, affordable and work in a wide variety of applications, from industrial machinery to transport solutions. The range is modular and flexible, making it easy to adapt the gearboxes to your needs.

Hydro-Mec is an Italian manufacturer known for high quality and smart solutions. The gearboxes are available in three different models – standard, square and stainless – and can be delivered both as complete units or in parts for quick adaptation.

Technical advantages at a glance

  • Torque from 21 Nm up to 347 Nm
  • Power ranges from 0.55 to 24 kW
  • 12 different gear ratios (7–96) – all in stock
  • Efficiency up to 88% at gear ratio 7
  • Cast aluminum housing, vacuum impregnated and ready for painting
  • Low weight and high strength
  • Lubricated for life with synthetic oil
  • Precision machined for quiet and safe operation

Flexible assembly and fast delivery

The gear units can be mounted in many different positions, with input and output shafts in multiple positions. We also stock a wide range of accessories such as IEC flanges, feet and single or double output shafts, which means we can quickly deliver a complete solution.

We can also provide you with quick help with configuration, CAD files and quotations. The gear units can be delivered unassembled or fully assembled – often within just a few days.

👉 Read more about Hydro-Mec’s worm gears on our website: mekanex.lv

Want to know more?

Do you have an application where the Hydro-Mec worm gear series could be suitable – or do you want to discuss the right gear for your project?

Feel free to contact us!
